NVMe M2 SSD 980PRO

(information from SamSung Spec)

Specifications

NVMe M2 SSD 980PRO

General Form FactorM.2 Capacity250GB, 500GB, 1TB, 2TB Sequential Read SpeedUp to 7,000 MB/s Sequential Write SpeedUp to 5,100 MB/s Specification Model Code (Capacity)MZ-V8P250BW (250GB) MZ-V8P500BW (500GB) MZ-V8P1T0BW (1TB) MZ-V8P2T0BW (2TB) General Feature ApplicationClient PCs FORM FACTORM.2 (2280) INTERFACEPCIe® Gen 4.0 x4, NVMe™ 1.3c DIMENSION (WxHxD)80.15 x 22.15 x 2.38 (mm) WEIGHTMax 9.0 g STORAGE MEMORYSamsung V-NAND 3-bit MLC CONTROLLERSamsung In-house Controller CACHE MEMORYSamsung 512MB Low Power DDR4 SDRAM (250/500GB) Samsung 1GB Low Power DDR4 SDRAM (1TB) Samsung 2GB Low Power DDR4 SDRAM (2TB) Special Feature TRIM SupportSupported S.M.A.R.T SupportSupported GC (GARBAGE COLLECTION)Auto Garbage Collection Algorithm ENCRYPTION SUPPORTAES 256-bit Encryption (Class 0), TCG/Opal, IEEE1667 (Encrypted drive) WWN SUPPORTNot Supported DEVICE SLEEP MODE SUPPORTYes Performance SEQUENTIAL READ250GB: Up to 6,400 MB/s 500GB: Up to 6,900 MB/s 1TB: Up to 7,000 MB/s 2TB: Up to 7,000 MB/s SEQUENTIAL WRITE250GB: Up to 2,700 MB/s 500GB: Up to 5,000 MB/s 1TB: Up to 5,000 MB/s 2TB: Up to 5,100 MB/s RANDOM READ (4KB, QD32)250GB: Up to 500,000 IOPS 500GB: Up to 800,000 IOPS 1TB: Up to 1,000,000 IOPS 2TB: Up to 1,000,000 IOPS RANDOM WRITE (4KB, QD32)250GB: Up to 600,000 IOPS 500GB: Up to 1,000,000 IOPS 1TB: Up to 1,000,000 IOPS 2TB: Up to 1,000,000 IOPS RANDOM READ (4KB, QD1)250GB: Up to 22,000 IOPS 500GB: Up to 22,000 IOPS 1TB: Up to 22,000 IOPS 2TB: Up to 22,000 IOPS RANDOM WRITE (4KB, QD1)250GB: Up to 60,000 IOPS 500GB: Up to 60,000 IOPS 1TB: Up to 60,000 IOPS 2TB: Up to 60,000 IOPS Environment AVERAGE POWER CONSUMPTION (System Level)250GB: Average 5 W Maximum 7 W 512GB: Average 5.9 W Maximum 7.4 W 1TB: Average 6.2 W Maximum 8.9 W 2TB: Average 6.1 W Maximum 7.2 W (Burst mode) POWER CONSUMPTION (IDLE)Max. 35 mW POWER CONSUMPTION (DEVICE SLEEP)Max. 5 mW ALLOWABLE VOLTAGE3.3 V ± 5 % Allowable voltage RELIABILITY (MTBF)1.5 Million Hours Reliability OPERATING TEMPERATURE0 - 70 ℃ Shock1,500 G & 0.5 ms (Half sine) Accessories INSTALLATION KITNot Available Software MANAGEMENT SWMagician Software for SSD management Warranty MZ-V8P250BW (250GB)5 Years or 150 TBW MZ-V8P500BW (500GB)5 Years or 300 TBW MZ-V8P1T0BW (1TB)5 Years or 600 TBW MZ-V8P2T0BW (2TB)5 Years or 1200 TBW
